HDSP-C3G3

Broadcom Limited
RoHS
/
Package 10-DIP (0.200, 5.08mm), 8 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description DISPLAY 0.36 SGL DGT CC GRN TH
PDF
/
Inventory: 5473
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
REACH SVHC No SVHC

Dimensions

Character Height 9.1mm
Viewing Area (height) 9.1mm
Height 13.9954mm

Technical

Dominant Wavelength 569 nm
Common Pin Common Cathode
Digit/Alpha Size 0.36 9.14mm
Number of Characters 1
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 565nm
Millicandela Rating 1.9mcd
Luminous Intensity 1.9 mcd
Forward Current 20mA
Voltage - Forward (Vf) (Typ) 2.25V
Power Dissipation 62.5mW
Element Configuration Common Cathode
Number of Elements 8
Reach Compliance Code unknown
Depth 7.5mm
Color Green
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.551 Hx0.295W x 0.335 D 14.00mmx7.50mmx8.50mm
Published 2010
Packaging Tube

Physical

Number of Pins 10
Package / Case 10-DIP (0.200, 5.08mm), 8 Leads
Mount Through Hole
