HDSP-C3E3
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.200, 5.08mm), 8 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
AVAGO TECHNOLOGIES HDSP-C3E3 7-Segment LED Display, 1, 9.1 mm, Red, Common Cathode, 1.1 mcd, 20 mA
PDF
/
Buying Options
Total Price: USD $1.51
Unit Price: USD $1.514686
≥1 USD $1.514686
≥10 USD $1.428956
≥100 USD $1.348061
≥500 USD $1.271763
≥1000 USD $1.199773
Inventory: 1451
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 9.1mm
Viewing Area (height) 9.1mm
Height 8.509mm
Technical
Character Width 4.8mm
Dominant Wavelength 626 nm
Common Pin Common Cathode
Digit/Alpha Size 0.36 9.14mm
Number of Segments 7
Number of Characters 1
Forward Voltage-Max 2.3V
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 640nm
Millicandela Rating 1.1mcd
Luminous Intensity 1.1 mcd
Forward Current 20mA
Power Dissipation 50mW
Element Configuration Common Cathode
Power Dissipation-Max 57.5mW
Number of Elements 8
Operating Supply Voltage 2V
Depth 7.5mm
Number of Functions 1
Subcategory LED Displays
Additional Feature HIGH RELIABILITY
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.551 Hx0.295W x 0.335 D 14.00mmx7.50mmx8.50mm
Published 2010
Packaging Tube
Physical
Number of Pins 10
Package / Case 10-DIP (0.200, 5.08mm), 8 Leads
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
