HDSP-C3E1

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 10-DIP (0.200, 5.08mm), 8 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description AVAGO TECHNOLOGIES HDSP-C3E1 7-Segment LED Display, 1, 9.1 mm, Red, Common Anode, 1.1 mcd, 20 mA
PDF
/
Inventory: 8398
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Through Hole
Package / Case 10-DIP (0.200, 5.08mm), 8 Leads
Number of Pins 10

Technical

Packaging Tube
Published 1996
Size / Dimension 0.551 Hx0.295W x 0.335 D 14.00mmx7.50mmx8.50mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Additional Feature HIGH RELIABILITY
Subcategory LED Displays
Number of Functions 1
Depth 7.5mm
Operating Supply Voltage 2V
Number of Elements 8
Power Dissipation-Max 57.5mW
Element Configuration Common Anode
Power Dissipation 50mW
Forward Current 20mA
Luminous Intensity 1.1 mcd
Millicandela Rating 1.1mcd
Wavelength - Peak 640nm
Display Type 7-Segment
Reverse Voltage 5V
Forward Voltage-Max 2.3V
Number of Characters 1
Number of Segments 7
Digit/Alpha Size 0.36 9.14mm
Common Pin Common Anode
Dominant Wavelength 626 nm
Character Width 4.8mm

Dimensions

Height 13.9954mm
Viewing Area (height) 9.1mm
Character Height 9.1mm

Compliance

REACH SVHC No SVHC
RoHS Status ROHS3 Compliant

Alternative Model

HDSP-C3E1+price,HDSP-C3E1+datasheet,HDSP-C3E1+in stock,buy+HDSP-C3E1,finder+HDSP-C3E1,HDSP-C3E1+tutorials,HDSP-C3E1+download
