HDSP-C2L3
RoHS
/
Package 10-DIP (2.370, 60.20mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
BROADCOM LIMITED HDSP-C2L3 7-Segment LED Display, Orange, 20 mA, 8.6 V, 20 mcd, 1, 56.8 mm
PDF
/
Inventory: 7373
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Character Height 56.8mm
Viewing Area (height) 56.8mm
Height 69.6976mm
Technical
Dominant Wavelength 605 nm
Common Pin Common Cathode
Digit/Alpha Size 2.30 58.42mm
Number of Characters 1
Forward Voltage-Max 9.2V
Reverse Voltage 20V
Display Type 7-Segment
Wavelength - Peak 610nm
Millicandela Rating 20mcd
Luminous Intensity 20 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 8.6V
Element Configuration Common Cathode
Power Dissipation-Max 230mW
Number of Elements 8
Reach Compliance Code unknown
Depth 69.7mm
Number of Functions 1
Subcategory LED Displays
Additional Feature HIGH RELIABILITY
Color Orange
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Size / Dimension 2.744 Hx1.882W x 0.472 D 69.70mmx47.80mmx12.00mm
Published 2010
Packaging Tube
Physical
Number of Pins 10
Package / Case 10-DIP (2.370, 60.20mm)
Mount Through Hole
