HDSP-C2E3
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (2.370, 60.20mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 2.3 SGL DGT CC RED TH
PDF
/
Inventory: 2585
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Display Height 56.8mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 2.30 58.42mm
Number of Characters 1
Forward Voltage-Max 9.2V
Display Type 7-Segment
Forward Current-Max 0.025A
Wavelength - Peak 640nm
Millicandela Rating 20mcd
Current - Test 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 8V
Power Dissipation-Max 230mW
Configuration COMPLEX
Operating Temperature (Min) -40°C
Operating Temperature (Max) 85°C
Number of Functions 1
Subcategory LED Displays
Additional Feature HIGH RELIABILITY
Color Red
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Size / Dimension 2.744 Hx1.882W x 0.472 D 69.70mmx47.80mmx12.00mm
Published 2011
Packaging Tube
Physical
Package / Case 10-DIP (2.370, 60.20mm)
