HDSP-C1Y1

Broadcom Limited
RoHS
/
Package 10-DIP (1.200, 30.48mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description BROADCOM LIMITED HDSP-C1Y1 7-Segment LED Display, Yellow, 20 mA, 4.3 V, 6.9 mcd, 1, 25.4 mm
PDF
/
Inventory: 6208
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Package / Case 10-DIP (1.200, 30.48mm)
Number of Pins 10

Technical

Packaging Tube
Published 1996
Size / Dimension 1.339 Hx0.945W x 0.413 D 34.00mmx24.00mmx10.50mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Color Yellow
Depth 34mm
Reach Compliance Code unknown
Number of Elements 8
Power Dissipation-Max 115mW
Element Configuration Common Anode
Voltage - Forward (Vf) (Typ) 4.3V
Forward Current 20mA
Luminous Intensity 6.9 mcd
Millicandela Rating 6.9mcd
Wavelength - Peak 587nm
Display Type 7-Segment
Reverse Voltage 10V
Number of Characters 1
Digit/Alpha Size 1.00 25.40mm
Common Pin Common Anode
Dominant Wavelength 589 nm

Dimensions

Height 34.0106mm
Viewing Area (height) 25.4mm
Character Height 25.4mm

Compliance

REACH SVHC No SVHC
RoHS Status RoHS Compliant
