HDSP-C1L3
RoHS
/
Package 10-DIP (1.200, 30.48mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
BROADCOM LIMITED HDSP-C1L3 7-Segment LED Display, Orange, 20 mA, 4.3 V, 12.1 mcd, 1, 25.4 mm
PDF
/
Inventory: 6767
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Package / Case 10-DIP (1.200, 30.48mm)
Number of Pins 10
Technical
Packaging Tube
Published 2010
Size / Dimension 1.339 Hx0.945W x 0.413 D 34.00mmx24.00mmx10.50mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Color Orange
Depth 34mm
Reach Compliance Code unknown
Number of Elements 8
Power Dissipation-Max 115mW
Element Configuration Common Cathode
Voltage - Forward (Vf) (Typ) 4.3V
Forward Current 20mA
Luminous Intensity 12.1 mcd
Millicandela Rating 12.1mcd
Wavelength - Peak 610nm
Display Type 7-Segment
Reverse Voltage 10V
Number of Characters 1
Digit/Alpha Size 1.00 25.40mm
Common Pin Common Cathode
Dominant Wavelength 605 nm
Dimensions
Height 34.0106mm
Viewing Area (height) 25.4mm
Character Height 25.4mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
