HDSP-C1A3
RoHS
/
Package 10-DIP (1.200, 30.48mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
BROADCOM LIMITED HDSP-C1A3 7-Segment LED Display, Red, 20 mA, 3.7 V, 42 mcd, 1, 25.4 mm
PDF
/
Inventory: 3993
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Character Height 25.4mm
Viewing Area (height) 25.4mm
Height 34.0106mm
Technical
Dominant Wavelength 643 nm
Common Pin Common Cathode
Digit/Alpha Size 1.00 25.40mm
Number of Characters 1
Forward Voltage-Max 4V
Reverse Voltage 10V
Display Type 7-Segment
Wavelength - Peak 660nm
Millicandela Rating 42mcd
Luminous Intensity 42 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 3.7V
Element Configuration Common Cathode
Power Dissipation-Max 100mW
Number of Elements 8
Operating Temperature (Min) -40°C
Reach Compliance Code unknown
Depth 34mm
Number of Functions 1
Subcategory LED Displays
Additional Feature HIGH RELIABILITY
Color Red
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Size / Dimension 1.339 Hx0.945W x 0.413 D 34.00mmx24.00mmx10.50mm
Published 2010
Packaging Tube
Physical
Number of Pins 10
Package / Case 10-DIP (1.200, 30.48mm)
Mount Through Hole
