HDSP-B03E
RoHS
RoHS compliant
RoHS compliantPackage 12-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
AVAGO TECHNOLOGIES HDSP-B03E 7-Segment LED Display, 4, 14.22 mm, Red, Common Cathode, 5.5 mcd, 20 mA
PDF
/
Inventory: 4038
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mount Through Hole
Package / Case 12-DIP (0.600, 15.24mm)
Number of Pins 12
Technical
Packaging Tube
Published 2001
Size / Dimension 0.752 Hx2.016W x 0.315 D 19.10mmx51.20mmx8.00mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Red
Character Width 7.8mm
Dominant Wavelength 622 nm
Common Pin Common Cathode
Digit/Alpha Size 0.56 14.22mm
Number of Segments 7
Number of Characters 4
Forward Voltage-Max 2.6V
Reverse Voltage 5V
Display Type 7-Segment Clock
Power Consumption 65mW
Wavelength - Peak 632nm
Millicandela Rating 5.5mcd
Luminous Intensity 5.5 mcd
Forward Current 20mA
Power Dissipation 65mW
Element Configuration Common Cathode
Number of Elements 30
Operating Supply Voltage 2.05V
Depth 19.1mm
Subcategory LED Displays
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 14.22mm
Viewing Area (height) 14.22mm
Height 7.874mm
