HDSP-A153
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
DISPLAY 7SEGMENT ALGAAS CC 0.3"
PDF
/
Buying Options
Total Price: USD $5.2
Unit Price: USD $5.2008
≥1 USD $5.2008
≥10 USD $3.67488
≥100 USD $3.01026
≥500 USD $2.537718
≥1000 USD $2.327697
≥3000 USD $2.231434
Inventory: 1163
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.200, 5.08mm)
Number of Pins 10
Technical
Packaging Bulk
Published 2006
Size / Dimension 0.500 Hx0.300W x 0.240 D 12.70mmx7.62mmx6.09mm
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 100°C
Min Operating Temperature -20°C
Color Red
Subcategory LED Displays
Number of Functions 1
Depth 9.79mm
Lead Pitch 2.54mm
Operating Supply Voltage 1.8V
Number of Elements 8
Row Spacing 5.08 mm
Power Dissipation-Max 96mW
Element Configuration Common Cathode
Power Dissipation 96mW
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 20mA
Luminous Intensity 14 mcd
Millicandela Rating 14mcd
Wavelength - Peak 645nm
Display Type 7-Segment
Reverse Voltage 15V
Forward Voltage-Max 3V
Number of Characters 1
Digit/Alpha Size 0.30 7.62mm
Common Pin Common Cathode
Dominant Wavelength 637 nm
Background Color White
Dimensions
Height 12.7mm
Viewing Area (height) 7.62mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
