HDSP-A151

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description AVAGO TECHNOLOGIES HDSP-A151 7-Segment LED Display, 1, 7.6 mm, Red, Common Anode, 14 mcd, 20 mA
PDF
/
Buying Options
Total Price: USD $4.14
Unit Price: USD $4.136
≥1 USD $4.136
≥10 USD $2.92512
≥100 USD $2.395536
≥500 USD $2.019486
≥1000 USD $1.852356
≥3000 USD $1.775761
Inventory: 1805
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Contact Plating Copper, Silver, Tin
Mount Through Hole
Package / Case 10-DIP (0.200, 5.08mm)
Number of Pins 10

Technical

Packaging Bulk
Published 2004
Size / Dimension 0.500 Hx0.300W x 0.240 D 12.70mmx7.62mmx6.09mm
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 100°C
Min Operating Temperature -20°C
Color Red
Subcategory LED Displays
Number of Functions 1
Depth 7.62mm
Operating Supply Voltage 1.8V
Number of Elements 8
Power Dissipation-Max 96mW
Element Configuration Common Anode
Power Dissipation 96mW
Forward Current 20mA
Luminous Intensity 14 mcd
Millicandela Rating 14mcd
Wavelength - Peak 645nm
Display Type 7-Segment
Reverse Voltage 15V
Forward Voltage-Max 3V
Number of Characters 1
Number of Segments 7
Digit/Alpha Size 0.30 7.62mm
Common Pin Common Anode
Dominant Wavelength 637 nm
Character Width 4.19mm

Dimensions

Height 6.096mm
Viewing Area (height) 7.62mm
Character Height 7.6mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
