HDSP-A113
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Red CC 10-Pin DIP
PDF
/
Buying Options
Total Price: USD $5.91
Unit Price: USD $5.90805
≥1 USD $5.90805
≥200 USD $2.357968
≥400 USD $2.279194
≥1000 USD $2.239807
Inventory: 5860
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Character Height 7.6mm
Viewing Area (height) 7.62mm
Height 12.7mm
Technical
Dominant Wavelength 637 nm
Common Pin Common Cathode
Digit/Alpha Size 0.30 7.62mm
Number of Characters 1
Forward Voltage-Max 2V
Reverse Voltage 15V
Display Type 7-Segment
Wavelength - Peak 645nm
Luminous Intensity 3.6 mcd
Current - Test 5mA
Forward Current 15mA
Voltage - Forward (Vf) (Typ) 1.7V
Power Dissipation 37mW
Element Configuration Common Cathode
Number of Elements 8
Operating Supply Voltage 1.8V
Depth 7.62mm
Number of Functions 1
Subcategory LED Displays
Color Red
Min Operating Temperature -20°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.500 Hx0.300W x 0.240 D 12.70mmx7.62mmx6.09mm
Published 2006
Packaging Bulk
Physical
Number of Pins 10
Package / Case 10-DIP (0.200, 5.08mm)
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
