HDSP-8606
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm), 14 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Green 571nm 0.8in 7 Segment
PDF
/
Inventory: 5839
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 18-DIP (0.600, 15.24mm), 14 Leads
Technical
Packaging Bulk
Published 2010
Size / Dimension 1.090 Hx0.786W x 0.330 D 27.69mmx19.96mmx8.38mm
JESD-609 Code e1
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Color Green
HTS Code 8531.20.00.40
Number of Functions 0.5
Reach Compliance Code compliant
Operating Temperature (Max) 100°C
Operating Temperature (Min) -40°C
Configuration SEPARATE, 0.5 DIGIT WITH DECIMAL POINT
Power Dissipation-Max 105mW
Voltage - Forward (Vf) (Typ) 2.1V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 10mA
Millicandela Rating 1.5mcd
Wavelength - Peak 566nm
Forward Current-Max 0.03A
Display Type 7-Segment
Number of Characters +/-1 (overflow)
Digit/Alpha Size 0.80 20.32mm
Common Pin Universal
Dimensions
Display Height 18.87mm
Compliance
RoHS Status RoHS Compliant
