HDSP-8600

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 18-DIP (0.600, 15.24mm), 12 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED Displays & Accessories Green 571nm 0.8in
PDF
/
Inventory: 4262
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Package / Case 18-DIP (0.600, 15.24mm), 12 Leads

Technical

Packaging Bulk
Published 2010
Size / Dimension 1.090 Hx0.786W x 0.330 D 27.69mmx19.96mmx8.38mm
JESD-609 Code e1
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Color Green
Number of Functions 1
Reach Compliance Code compliant
Operating Temperature (Min) -40°C
Power Dissipation-Max 105mW
Voltage - Forward (Vf) (Typ) 2.1V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 10mA
Millicandela Rating 1.5mcd
Wavelength - Peak 566nm
Forward Current-Max 0.03A
Display Type 7-Segment
Number of Characters 1
Digit/Alpha Size 0.80 20.32mm
Common Pin Common Anode

Dimensions

Display Height 20.32mm

Compliance

RoHS Status RoHS Compliant
