HDSP-815E

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 16-DIP (0.600, 15.24mm), 12 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description AVAGO TECHNOLOGIES HDSP-815E 7-Segment LED Display, 1, 20 mm, Red, Common Anode, 4.8 mcd, 20 mA
PDF
/
Buying Options
Total Price: USD $1.97
Unit Price: USD $1.9712
≥1 USD $1.9712
≥10 USD $1.3156
≥100 USD $1.012352
≥500 USD $0.915112
≥1000 USD $0.786421
≥3000 USD $0.743521
Inventory: 1015
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Through Hole
Package / Case 16-DIP (0.600, 15.24mm), 12 Leads
Number of Pins 16

Technical

Packaging Bulk
Published 2000
Size / Dimension 1.090 Hx0.786W x 0.330 D 27.69mmx19.96mmx8.38mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Color Red
Subcategory LED Displays
Number of Functions 1
Depth 19.96mm
Operating Supply Voltage 2.1V
Number of Elements 8
Power Dissipation-Max 62.5mW
Element Configuration Common Anode
Power Dissipation 62.5mW
Forward Current 20mA
Luminous Intensity 4.8 mcd
Millicandela Rating 4.8mcd
Wavelength - Peak 635nm
Display Type 7-Segment
Reverse Voltage 25V
Forward Voltage-Max 3V
Number of Characters 1
Number of Segments 7
Digit/Alpha Size 0.80 20.32mm
Common Pin Common Anode
Dominant Wavelength 626 nm
Character Width 11.07mm

Dimensions

Height 27.686mm
Viewing Area (height) 20.32mm
Character Height 20mm

Compliance

REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
