HDSP-7801
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
AVAGO TECHNOLOGIES HDSP-7801 7-Segment LED Display, 1, 7.6 mm, Green, Common Anode, 6.8 mcd, 20 mA
PDF
/
Buying Options
Total Price: USD $3.4
Unit Price: USD $3.3968
≥1 USD $3.3968
≥10 USD $2.402048
≥100 USD $1.967504
≥500 USD $1.658642
≥1000 USD $1.52137
≥3000 USD $1.458459
Inventory: 1216
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Character Height 7.6mm
Viewing Area (height) 7.62mm
Height 12.7mm
Technical
Character Width 4.19mm
Dominant Wavelength 571 nm
Common Pin Common Anode
Digit/Alpha Size 0.30 7.62mm
Number of Segments 7
Number of Characters 1
Forward Voltage-Max 2.5V
Reverse Voltage 50V
Display Type 7-Segment
Wavelength - Peak 566nm
Luminous Intensity 6.8 mcd
Current - Test 10mA
Forward Current 20mA
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation 105mW
Element Configuration Common Anode
Number of Elements 8
Depth 7.62mm
Number of Functions 1
Subcategory LED Displays
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.500 Hx0.300W x 0.240 D 12.70mmx7.62mmx6.09mm
Published 2004
Packaging Tube
Physical
Number of Pins 10
Package / Case 10-DIP (0.200, 5.08mm)
Mount Through Hole
Contact Plating Copper, Silver, Tin
Supply Chain
Factory Lead Time 16 Weeks
