HDSP-7518
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.200, 5.08mm), 7 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Red 626nm 0.3in
PDF
/
Inventory: 4785
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Display Height 7.6mm
Technical
Common Pin Common Cathode
Digit/Alpha Size 0.30 7.62mm
Number of Characters +/-1 (overflow)
Display Type 7-Segment
Forward Current-Max 0.015A
Wavelength - Peak 635nm
Millicandela Rating 1.05mcd
Current - Test 5mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 1.7V
Power Dissipation-Max 52mW
Operating Temperature (Min) -40°C
Operating Temperature (Max) 100°C
Reach Compliance Code compliant
Number of Functions 0.5
HTS Code 8531.20.00.40
Color Red
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e1
Size / Dimension 0.500 Hx0.300W x 0.390 D 12.70mmx7.62mmx9.91mm
Published 2006
Packaging Bulk
Physical
Package / Case 10-DIP (0.200, 5.08mm), 7 Leads
