HDSP-7503
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
AVAGO TECHNOLOGIES HDSP-7503 7-Segment LED Display, 1, 7.6 mm, Red, Common Cathode, 5.39 mcd, 20 mA
PDF
/
Buying Options
Total Price: USD $3.4
Unit Price: USD $3.3968
≥1 USD $3.3968
≥10 USD $2.402048
≥100 USD $1.967504
≥500 USD $1.658642
≥1000 USD $1.52137
≥3000 USD $1.458459
Inventory: 3592
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.200, 5.08mm)
Number of Pins 10
Technical
Packaging Tube
Published 2004
Size / Dimension 0.500 Hx0.300W x 0.240 D 12.70mmx7.62mmx6.09mm
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Red
Subcategory LED Displays
Number of Functions 1
Depth 9.79mm
Operating Supply Voltage 2V
Number of Elements 8
Power Dissipation-Max 105mW
Element Configuration Common Cathode
Power Dissipation 105mW
Viewing Angle 50 °
Forward Current 20mA
Luminous Intensity 5.39 mcd
Millicandela Rating 5.39mcd
Wavelength - Peak 635nm
Display Type 7-Segment
Reverse Voltage 30V
Forward Voltage-Max 2.5V
Number of Characters 1
Number of Segments 7
Digit/Alpha Size 0.30 7.62mm
Common Pin Common Cathode
Dominant Wavelength 626 nm
Character Width 4.19mm
Dimensions
Height 12.7mm
Viewing Area (height) 7.62mm
Character Height 7.6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
