HDSP-7502
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 9LED Hi-Eff. Red CA 10-Pin DIP Tube
PDF
/
Inventory: 10007
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Display Height 7.6mm
Technical
Common Pin Common Anode
Digit/Alpha Size 0.30 7.62mm
Number of Characters 1
Forward Voltage-Max 2.5V
Display Type 7-Segment
Forward Current-Max 0.03A
Wavelength - Peak 635nm
Millicandela Rating 5.39mcd
Current - Test 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation-Max 105mW
Operating Temperature (Min) -40°C
Number of Functions 1
Subcategory LED Displays
Color Red
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e1
Size / Dimension 0.500 Hx0.300W x 0.240 D 12.70mmx7.62mmx6.09mm
Published 2006
Packaging Bulk
Physical
Package / Case 10-DIP (0.200, 5.08mm)
