HDSP-7501-CD000
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED 7-SEG 7.6MM CA HE RED
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8303
≥1 USD $0.8303
≥10 USD $0.68115
≥100 USD $0.66025
≥500 USD $0.6384
≥1000 USD $0.6175
Inventory: 1447
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Character Height 7.6mm
Viewing Area (height) 7.62mm
Height 12.7mm
Technical
Character Width 4.19mm
Dominant Wavelength 626 nm
Common Pin Common Anode
Digit/Alpha Size 0.30 7.62mm
Number of Segments 7
Number of Characters 1
Forward Voltage-Max 2.5V
Reverse Voltage 30V
Display Type 7-Segment
Wavelength - Peak 635nm
Millicandela Rating 5.39mcd
Luminous Intensity 5.39 mcd
Forward Current 20mA
Power Dissipation 105mW
Element Configuration Common Anode
Power Dissipation-Max 105mW
Number of Elements 8
Operating Supply Voltage 2V
Depth 7.62mm
Number of Functions 1
Subcategory LED Displays
Color Red
Min Operating Temperature -20°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.500 Hx0.300W x 0.240 D 12.70mmx7.62mmx6.09mm
Published 2002
Packaging Bulk
Physical
Number of Pins 10
Package / Case 10-DIP (0.200, 5.08mm)
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
