HDSP-7403

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 10-DIP (0.200, 5.08mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description DISPLAY 7SEGMENT YELLOW CC 0.3"
PDF
/
Buying Options
Total Price: USD $2.91
Unit Price: USD $2.9128
≥1 USD $2.9128
≥10 USD $2.061664
≥100 USD $1.688456
≥500 USD $1.423418
≥1000 USD $1.305612
≥3000 USD $1.251624
Inventory: 1126
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Character Height 6.09mm
Viewing Area (height) 7.62mm
Height 12.7mm

Technical

Dominant Wavelength 586 nm
Common Pin Common Cathode
Digit/Alpha Size 0.30 7.62mm
Number of Characters 1
Reverse Voltage 50V
Display Type 7-Segment
Wavelength - Peak 583nm
Millicandela Rating 2.74mcd
Luminous Intensity 2.74 mcd
Forward Current 20mA
Voltage - Forward (Vf) (Typ) 2.2V
Power Dissipation 80mW
Element Configuration Common Cathode
Number of Elements 8
Operating Supply Voltage 2V
Depth 9.79mm
Number of Functions 1
Color Yellow
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish TIN/TIN SILVER COPPER
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.500 Hx0.300W x 0.240 D 12.70mmx7.62mmx6.09mm
Published 2006
Packaging Tube

Physical

Number of Pins 10
Package / Case 10-DIP (0.200, 5.08mm)
Mount Through Hole

Supply Chain

Factory Lead Time 13 Weeks
