HDSP-5703-FG000
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Yellow CC 10-Pin DIP
PDF
/
Inventory: 7433
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 10-DIP (0.600, 15.24mm)
Technical
Packaging Bulk
Published 2014
Size / Dimension 0.670 Hx0.495W x 0.315 D 17.02mmx12.57mmx8.00mm
JESD-609 Code e1
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Color Yellow
Subcategory LED Displays
Number of Functions 1
Reach Compliance Code compliant
Operating Temperature (Min) -40°C
Power Dissipation-Max 80mW
Voltage - Forward (Vf) (Typ) 2.1V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 20mA
Millicandela Rating 1.8mcd
Wavelength - Peak 583nm
Forward Current-Max 0.02A
Display Type 7-Segment
Forward Voltage-Max 2.5V
Number of Characters 1
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Cathode
Compliance
RoHS Status RoHS Compliant
