HDSP-561A
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Red CA 10-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $1.49
Unit Price: USD $1.488829
≥1 USD $1.488829
≥320 USD $0.594744
≥640 USD $0.57505
≥960 USD $0.564547
Inventory: 7879
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mount Through Hole
Package / Case 10-DIP (0.600, 15.24mm)
Number of Pins 10
Technical
Packaging Bulk
Size / Dimension 0.689 Hx0.482W x 0.276 D 17.50mmx12.25mmx7.00mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 80°C
Min Operating Temperature -20°C
Color Red
Subcategory LED Displays
Depth 9.7mm
Operating Supply Voltage 1.8V
Number of Elements 8
Power Dissipation-Max 37mW
Element Configuration Common Anode
Power Dissipation 37mW
Optoelectronic Device Type 7 SEG NUMERIC LED DISPLAY
Forward Current 20mA
Luminous Intensity 450 μcd
Millicandela Rating 0.45mcd
Wavelength - Peak 660nm
Display Type 7-Segment
Reverse Voltage 5V
Forward Voltage-Max 2.2V
Number of Characters 1
Digit/Alpha Size 0.52 13.21mm
Common Pin Common Anode
Dominant Wavelength 643 nm
Dimensions
Height 17.5006mm
Viewing Area (height) 13mm
Compliance
RoHS Status ROHS3 Compliant
