HDSP-5601-GH000
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Green 571nm 0.56in 7 Segment
PDF
/
Buying Options
Total Price: USD $3.31
Unit Price: USD $3.3088
≥1 USD $3.3088
Inventory: 47
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Plating Copper, Silver, Tin
Mount Through Hole
Package / Case 10-DIP (0.600, 15.24mm)
Number of Pins 10
Technical
Packaging Bulk
Published 2010
Size / Dimension 0.670 Hx0.495W x 0.315 D 17.02mmx12.57mmx8.00mm
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Green
Subcategory LED Displays
Number of Functions 1
Depth 17.02mm
Operating Supply Voltage 2.1V
Number of Elements 8
Power Dissipation-Max 105mW
Element Configuration Common Anode
Power Dissipation 105mW
Forward Current 30mA
Current - Test 10mA
Luminous Intensity 2.5 mcd
Wavelength - Peak 566nm
Display Type 7-Segment
Reverse Voltage 50V
Forward Voltage-Max 2.5V
Number of Characters 1
Number of Segments 7
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Anode
Dominant Wavelength 571 nm
Character Width 7.8mm
Dimensions
Height 17.018mm
Viewing Area (height) 14.22mm
Character Height 14.22mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
