HDSP-5553

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description AVAGO TECHNOLOGIES HDSP-5553 7-Segment LED Display, 1, 14.2 mm, Red, Common Cathode, 1.48 mcd, 20 mA
PDF
/
Buying Options
Total Price: USD $3.31
Unit Price: USD $3.3088
≥1 USD $3.3088
≥10 USD $2.33662
≥100 USD $1.91385
≥500 USD $1.613392
≥1000 USD $1.479878
≥3000 USD $1.418683
Inventory: 291
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Character Height 14.2mm
Viewing Area (height) 14.22mm
Height 17.018mm

Technical

Character Width 7.8mm
Dominant Wavelength 626 nm
Common Pin Common Cathode
Digit/Alpha Size 0.56 14.22mm
Number of Segments 7
Number of Characters 1
Reverse Voltage 30V
Display Type 7-Segment
Wavelength - Peak 635nm
Luminous Intensity 1.48 mcd
Current - Test 5mA
Forward Current 20mA
Power Dissipation 52mW
Element Configuration Common Cathode
Power Dissipation-Max 52mW
Number of Elements 8
Operating Supply Voltage 1.7V
Depth 17.02mm
Number of Functions 1
Subcategory LED Displays
Color Red
Min Operating Temperature -20°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.670 Hx0.495W x 0.315 D 17.02mmx12.57mmx8.00mm
Published 2002
Packaging Tube

Physical

Number of Pins 10
Package / Case 10-DIP (0.600, 15.24mm)
Mount Through Hole
Contact Plating Copper, Silver, Tin

Supply Chain

Factory Lead Time 16 Weeks
