HDSP-5538
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm), 9 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Red 626nm 0.56in
PDF
/
Inventory: 1736
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 10-DIP (0.600, 15.24mm), 9 Leads
Technical
Packaging Bulk
Published 2006
Size / Dimension 0.670 Hx0.495W x 0.315 D 17.02mmx12.57mmx8.00mm
JESD-609 Code e1
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Color Red
Additional Feature IC COMPATIBLE
HTS Code 8531.20.00.40
Number of Functions 0.5
Reach Compliance Code compliant
Operating Temperature (Max) 85°C
Operating Temperature (Min) -40°C
Power Dissipation-Max 105mW
Voltage - Forward (Vf) (Typ) 2.6V
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Current - Test 100mA
Millicandela Rating 7mcd
Wavelength - Peak 635nm
Forward Current-Max 0.04A
Display Type 7-Segment
Number of Characters +/-1 (overflow)
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Cathode
Dimensions
Display Height 14.1mm
Compliance
RoHS Status RoHS Compliant
