HDSP-5503-GH000

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED 7-SEG 14.2MM CC HE RED RHD
PDF
/
Buying Options
Total Price: USD $2.77
Unit Price: USD $2.76545
≥1 USD $2.76545
≥10 USD $2.26955
≥100 USD $2.1983
≥500 USD $2.12705
≥1000 USD $2.05675
Inventory: 1524
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Through Hole
Package / Case 10-DIP (0.600, 15.24mm)
Number of Pins 10

Technical

Packaging Bulk
Published 2010
Size / Dimension 0.670 Hx0.495W x 0.315 D 17.02mmx12.57mmx8.00mm
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Red
Subcategory LED Displays
Number of Functions 1
Depth 17.02mm
Operating Supply Voltage 2.1V
Number of Elements 8
Element Configuration Common Cathode
Power Dissipation 105mW
Forward Current 30mA
Current - Test 20mA
Luminous Intensity 3.7 mcd
Millicandela Rating 2.8mcd
Wavelength - Peak 635nm
Power Consumption 105mW
Display Type 7-Segment
Reverse Voltage 30V
Forward Voltage-Max 2.5V
Number of Characters 1
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Cathode
Dominant Wavelength 626 nm

Dimensions

Height 17.018mm
Viewing Area (height) 14.22mm
Character Height 14.22mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
