HDSP-5501
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
AVAGO TECHNOLOGIES HDSP-5501 7-Segment LED Display, 1, 14.22 mm, Red, Common Anode, 3.7 mcd, 20 mA
PDF
/
Buying Options
Total Price: USD $3.09
Unit Price: USD $3.0888
≥1 USD $3.0888
≥10 USD $2.18372
≥100 USD $1.7886
≥500 USD $1.507845
≥1000 USD $1.383061
≥3000 USD $1.32587
Inventory: 996
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Character Height 14.22mm
Viewing Area (height) 14.22mm
Height 17.018mm
Technical
Character Width 7.8mm
Dominant Wavelength 626 nm
Common Pin Common Anode
Digit/Alpha Size 0.56 14.22mm
Number of Segments 7
Number of Characters 1
Forward Voltage-Max 2.5V
Reverse Voltage 30V
Display Type 7-Segment
Power Consumption 105mW
Wavelength - Peak 635nm
Millicandela Rating 2.8mcd
Luminous Intensity 3.7 mcd
Forward Current 20mA
Voltage - Forward (Vf) (Typ) 2.1V
Power Dissipation 105mW
Element Configuration Common Anode
Number of Elements 8
Depth 17.02mm
Number of Functions 1
Subcategory LED Displays
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.670 Hx0.495W x 0.315 D 17.02mmx12.57mmx8.00mm
Published 2004
Packaging Tube
Physical
Number of Pins 10
Package / Case 10-DIP (0.600, 15.24mm)
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
