HDSP-523E

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 18-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description AVAGO TECHNOLOGIES HDSP-523E 7-Segment LED Display, 2, 14.2 mm, Red, Common Cathode, 4 mcd, 20 mA
PDF
/
Buying Options
Total Price: USD $2.43
Unit Price: USD $2.4288
≥1 USD $2.4288
≥10 USD $1.6192
≥100 USD $1.24608
≥500 USD $1.126418
≥1000 USD $0.968009
≥3000 USD $0.915218
Inventory: 1289
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Through Hole
Package / Case 18-DIP (0.600, 15.24mm)
Number of Pins 18

Technical

Packaging Tube
Published 2001
Size / Dimension 0.732 Hx0.984W x 0.315 D 18.60mmx25.00mmx8.00mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -35°C
Color Red
Subcategory LED Displays
Number of Functions 2
Depth 18.6mm
Operating Supply Voltage 2.05V
Number of Elements 16
Element Configuration Common Cathode
Power Dissipation 62.5mW
Forward Current 20mA
Luminous Intensity 4 mcd
Millicandela Rating 4mcd
Wavelength - Peak 640nm
Power Consumption 62.5mW
Display Type 7-Segment
Reverse Voltage 5V
Number of Characters 2
Number of Segments 14
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Cathode
Dominant Wavelength 628 nm
Character Width 7.8mm

Dimensions

Height 18.5928mm
Viewing Area (height) 14.22mm
Character Height 14.2mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free

Alternative Model
