HDSP-521G
RoHS
RoHS compliant
RoHS compliantPackage 18-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
AVAGO TECHNOLOGIES HDSP-521G 7-Segment LED Display, 2, 14.2 mm, Green, Common Anode, 3.5 mcd, 10 mA
PDF
/
Buying Options
Total Price: USD $2.43
Unit Price: USD $2.4288
≥1 USD $2.4288
≥10 USD $1.6192
≥100 USD $1.24608
≥500 USD $1.126418
≥1000 USD $0.968009
≥3000 USD $0.915218
Inventory: 17694
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Package / Case 18-DIP (0.600, 15.24mm)
Number of Pins 18
Technical
Packaging Tube
Published 2001
Size / Dimension 0.732 Hx0.984W x 0.315 D 18.60mmx25.00mmx8.00mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -35°C
Color Green
Subcategory LED Displays
Number of Functions 2
Depth 18.6mm
Number of Elements 16
Element Configuration Common Anode
Power Dissipation 105mW
Voltage - Forward (Vf) (Typ) 2V
Forward Current 10mA
Luminous Intensity 3.5 mcd
Millicandela Rating 3.5mcd
Wavelength - Peak 568nm
Power Consumption 105mW
Display Type 7-Segment
Reverse Voltage 5V
Number of Characters 2
Number of Segments 14
Digit/Alpha Size 0.56 14.22mm
Common Pin Common Anode
Dominant Wavelength 570 nm
Character Width 7.8mm
Dimensions
Height 18.5928mm
Viewing Area (height) 14.22mm
Character Height 14.2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
