HDSP-515H-GH000
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Red CA 10-Pin DIP Tube
PDF
/
Inventory: 9321
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Common Pin Common Anode
Digit/Alpha Size 0.51 13.00mm
Number of Characters 1
Display Type 7-Segment
Wavelength - Peak 645nm
Millicandela Rating 0.65mcd
Current - Test 1mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 1.8V
Power Dissipation-Max 37mW
Operating Temperature (Min) -20°C
Reach Compliance Code compliant
Number of Functions 1
Color Red
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e1
Size / Dimension 0.689 Hx0.482W x 0.276 D 17.50mmx12.25mmx7.00mm
Published 2013
Packaging Bulk
Physical
Package / Case 10-DIP (0.600, 15.24mm)
