HDSP-513Y

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description 14.22 MM (0.56 INCH) GENERAL PURPOSE SEVEN-SEGMENT DISPLAY
PDF
/
Buying Options
Total Price: USD $1.65
Unit Price: USD $1.645064
≥1 USD $1.645064
≥200 USD $0.65645
≥400 USD $0.634131
≥800 USD $0.623628
Inventory: 4361
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Viewing Area (height) 14.22mm
Height 17.0942mm

Technical

Dominant Wavelength 590 nm
Common Pin Common Cathode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 1
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 595nm
Millicandela Rating 2.6mcd
Luminous Intensity 2.6 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Power Dissipation 52mW
Element Configuration Common Cathode
Power Dissipation-Max 52mW
Number of Elements 8
Operating Supply Voltage 2.15V
Depth 17.1mm
Number of Functions 1
Color Yellow
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.673 Hx0.488W x 0.315 D 17.10mmx12.40mmx8.00mm
Packaging Bulk

Physical

Number of Pins 10
Package / Case 10-DIP (0.600, 15.24mm)
Mount Through Hole

Supply Chain

Factory Lead Time 16 Weeks
