HDSP-513E

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 10-DIP (0.600, 15.24mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description 14.22 MM (0.56 INCH) GENERAL PURPOSE SEVEN-SEGMENT DISPLAY
PDF
/
Buying Options
Total Price: USD $1.73
Unit Price: USD $1.7336
≥1 USD $1.7336
≥10 USD $1.1
≥100 USD $0.81378
≥500 USD $0.659815
≥1000 USD $0.615824
≥3000 USD $0.585042
Inventory: 1305
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Viewing Area (height) 14.22mm
Height 8mm

Technical

Dominant Wavelength 620 nm
Common Pin Common Cathode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 1
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 635nm
Millicandela Rating 4.1mcd
Luminous Intensity 4.1 mcd
Forward Current 20mA
Viewing Angle 100 °
Power Dissipation 60mW
Element Configuration Common Cathode
Power Dissipation-Max 60mW
Number of Elements 8
Operating Supply Voltage 2.05V
Depth 17.1mm
Number of Functions 1
Color Red
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.673 Hx0.488W x 0.315 D 17.10mmx12.40mmx8.00mm
Packaging Bulk

Physical

Number of Pins 10
Package / Case 10-DIP (0.600, 15.24mm)
Mount Through Hole

Supply Chain

Factory Lead Time 16 Weeks
