HDSP-4606
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm), 12 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Green 571nm 0.43in 7 Segment
PDF
/
Buying Options
Total Price: USD $19.46
Unit Price: USD $19.45695
≥1 USD $19.45695
≥10 USD $15.96475
≥100 USD $15.466
≥500 USD $14.9663
≥1000 USD $14.46755
Inventory: 3775
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Mount Through Hole
Package / Case 14-DIP (0.300, 7.62mm), 12 Leads
Number of Pins 14
Technical
Packaging Bulk
Published 2011
Size / Dimension 0.750 Hx0.500W x 0.250 D 19.05mmx12.70mmx6.35mm
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Green
HTS Code 8531.20.00.40
Subcategory LED Displays
Number of Functions 0.5
Depth 12.7mm
Operating Supply Voltage 2.1V
Number of Elements 6
Configuration SEPARATE, 0.5 DIGIT WITH DECIMAL POINT
Power Dissipation 105mW
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 10mA
Luminous Intensity 4 mcd
Millicandela Rating 4mcd
Wavelength - Peak 566nm
Power Consumption 105mW
Display Type 7-Segment
Reverse Voltage 50V
Forward Voltage-Max 2.5V
Number of Characters +/-1 (overflow)
Digit/Alpha Size 0.43 11.00mm
Common Pin Universal
Dominant Wavelength 571 nm
Character Width 10.9mm
Dimensions
Height 19.05mm
Viewing Area (height) 10.31mm
Character Height 10.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
