HDSP-433G
RoHS
RoHS compliant
RoHS compliantPackage 15-DIP (0.400, 10.16mm), 12 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
AVAGO TECHNOLOGIES HDSP-433G 7-Segment LED Display, 3, 10 mm, Green, Common Cathode, 5 mcd, 20 mA
PDF
/
Buying Options
Total Price: USD $4.73
Unit Price: USD $4.7344
≥1 USD $4.7344
≥10 USD $3.34576
≥100 USD $2.74017
≥500 USD $2.310026
≥1000 USD $2.118846
≥3000 USD $2.031225
Inventory: 4656
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 10mm
Viewing Area (height) 10mm
Height 7.112mm
Technical
Dominant Wavelength 573 nm
Common Pin Common Cathode
Digit/Alpha Size 0.40 10.16mm
Number of Characters 3
Reverse Voltage 3V
Display Type 7-Segment
Wavelength - Peak 568nm
Millicandela Rating 5mcd
Luminous Intensity 5 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Power Dissipation 65mW
Element Configuration Common Cathode
Power Dissipation-Max 65mW
Number of Elements 27
Operating Supply Voltage 2.25V
Depth 12.8mm
HTS Code 8541.40.20.00
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Terminal Finish Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.504 Hx1.182W x 0.276 D 12.80mmx30.02mmx7.00mm
Published 2007
Packaging Bulk
Physical
Number of Pins 12
Package / Case 15-DIP (0.400, 10.16mm), 12 Leads
Mount Through Hole
Supply Chain
Factory Lead Time 22 Weeks
