HDSP-333A
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm), 10 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Red CC 14-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.806762
≥1 USD $0.806762
Inventory: 4803
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Package / Case 14-DIP (0.300, 7.62mm), 10 Leads
Number of Pins 14
Technical
Packaging Bulk
Size / Dimension 0.748 Hx0.398W x 0.240 D 19.00mmx10.10mmx6.10mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -35°C
Color Red
Subcategory LED Displays
Depth 10.1mm
Operating Supply Voltage 1.85V
Number of Elements 8
Power Dissipation-Max 30mW
Element Configuration Common Cathode
Power Dissipation 30mW
Optoelectronic Device Type 7 SEG NUMERIC LED DISPLAY
Forward Current 15mA
Current - Test 20mA
Luminous Intensity 4.2 mcd
Wavelength - Peak 660nm
Display Type 7-Segment
Reverse Voltage 5V
Forward Voltage-Max 2V
Number of Characters 1
Digit/Alpha Size 0.30 7.62mm
Common Pin Common Cathode
Dominant Wavelength 643 nm
Dimensions
Height 18.9992mm
Viewing Area (height) 7.62mm
Compliance
RoHS Status ROHS3 Compliant
