HDSP-316Y
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.300, 7.62mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Displays Module 1DIGIT 8LED Yellow CC 10-Pin DIP Tube
PDF
/
Buying Options
Total Price: USD $13.41
Unit Price: USD $13.4102
≥1 USD $13.4102
≥10 USD $11.00385
≥100 USD $10.65995
≥500 USD $10.31605
≥1000 USD $9.97215
Inventory: 1263
Minimum: 1
-
+
Technical Details
Technical
Millicandela Rating 1.8mcd
Wavelength - Peak 583nm
Forward Current-Max 0.03A
Display Type 7-Segment
Forward Voltage-Max 2.5V
Number of Characters 1
Digit/Alpha Size 0.40 10.16mm
Common Pin Common Cathode
Current - Test 10mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2V
Power Dissipation-Max 105mW
Operating Temperature (Min) -40°C
Reach Compliance Code compliant
Number of Functions 1
Subcategory LED Displays
Color Yellow
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e1
Size / Dimension 0.504 Hx0.382W x 0.276 D 12.80mmx9.70mmx7.00mm
Published 2014
Packaging Bulk
Compliance
RoHS Status RoHS Compliant
Physical
Package / Case 10-DIP (0.300, 7.62mm)
