HDSP-315E
RoHS
/
Package 10-DIP (0.300, 7.62mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
AVAGO TECHNOLOGIES HDSP-315E 7-Segment LED Display, 1, 10 mm, Red, Common Anode, 2.6 mcd, 10 mA
PDF
/
Buying Options
Total Price: USD $9.06
Unit Price: USD $9.06205
≥1 USD $9.06205
≥10 USD $7.43565
≥100 USD $7.2029
≥500 USD $6.9711
≥1000 USD $6.73835
Inventory: 16
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Character Height 10mm
Viewing Area (height) 10mm
Height 12.8016mm
Technical
Character Width 6mm
Dominant Wavelength 626 nm
Common Pin Common Anode
Digit/Alpha Size 0.40 10.16mm
Number of Segments 7
Number of Characters 1
Forward Voltage-Max 2.5V
Reverse Voltage 30V
Display Type 7-Segment
Power Consumption 105mW
Wavelength - Peak 635nm
Millicandela Rating 2.6mcd
Luminous Intensity 2.6 mcd
Forward Current 10mA
Power Dissipation 105mW
Element Configuration Common Anode
Number of Elements 8
Operating Supply Voltage 1.9V
Reach Compliance Code unknown
Depth 9.7mm
Number of Functions 1
Subcategory LED Displays
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e1
Size / Dimension 0.504 Hx0.382W x 0.276 D 12.80mmx9.70mmx7.00mm
Published 2009
Packaging Bulk
Physical
Number of Pins 10
Package / Case 10-DIP (0.300, 7.62mm)
Mount Through Hole
