HDSP-311G

Broadcom Limited
RoHS
/
Package 14-DIP (0.300, 7.62mm), 10 Leads
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED Displays & Accessories Green 573nm 0.4in 7 Segment
PDF
/
Inventory: 8313
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Viewing Area (height) 10.16mm
Height 18.7452mm

Technical

Dominant Wavelength 573 nm
Common Pin Common Anode
Digit/Alpha Size 0.40 10.16mm
Number of Characters 1
Forward Voltage-Max 2.6V
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 568nm
Millicandela Rating 3.2mcd
Luminous Intensity 3.2 mcd
Forward Current 10mA
Optoelectronic Device Type 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.06V
Power Dissipation 65mW
Element Configuration Common Anode
Number of Elements 8
Depth 9.8mm
Subcategory LED Displays
Color Green
Min Operating Temperature -35°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Size / Dimension 0.738 Hx0.386W x 0.201 D 18.75mmx9.80mmx5.10mm
Packaging Bulk

Physical

Number of Pins 14
Package / Case 14-DIP (0.300, 7.62mm), 10 Leads
Mount Through Hole

Supply Chain

Factory Lead Time 14 Weeks
