HDSP-303Y

Broadcom Limited
RoHS
/
Package 10-DIP (0.300, 7.62mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description LED Displays & Accessories Yellow 590nm 10mm 7 Segment
PDF
/
Inventory: 4125
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Viewing Area (height) 10mm
Height 12.8016mm

Technical

Dominant Wavelength 590 nm
Common Pin Common Cathode
Digit/Alpha Size 0.40 10.16mm
Number of Characters 1
Forward Voltage-Max 2.5V
Display Type 7-Segment
Wavelength - Peak 589nm
Luminous Intensity 1.8 mcd
Current - Test 20mA
Forward Current 10mA
Optoelectronic Device Type 7 SEG NUMERIC LED DISPLAY
Voltage - Forward (Vf) (Typ) 2.15V
Element Configuration Common Cathode
Power Dissipation-Max 105mW
Subcategory LED Displays
Color Yellow
Min Operating Temperature -40°C
Max Operating Temperature 80°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Size / Dimension 0.504 Hx0.382W x 0.276 D 12.80mmx9.70mmx7.00mm
Published 2007
Packaging Bulk

Physical

Number of Pins 10
Package / Case 10-DIP (0.300, 7.62mm)
