HDSP-303G
RoHS
RoHS compliant
RoHS compliantPackage 10-DIP (0.300, 7.62mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED Displays & Accessories Green 573nm 10mm 7 Segment
PDF
/
Buying Options
Total Price: USD $1.68
Unit Price: USD $1.680512
≥1 USD $1.680512
≥200 USD $0.670892
≥500 USD $0.648573
≥1000 USD $0.636757
Inventory: 4252
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Character Height 10mm
Viewing Area (height) 10mm
Height 12.8016mm
Technical
Dominant Wavelength 573 nm
Common Pin Common Cathode
Digit/Alpha Size 0.40 10.16mm
Number of Characters 1
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 568nm
Millicandela Rating 2.8mcd
Luminous Intensity 3.2 mcd
Forward Current 20mA
Optoelectronic Device Type 7 SEG NUMERIC LED DISPLAY
Power Dissipation 105mW
Element Configuration Common Cathode
Power Dissipation-Max 105mW
Number of Elements 8
Operating Supply Voltage 2.25V
Depth 9.7mm
Subcategory LED Displays
Color Green
Min Operating Temperature -40°C
Max Operating Temperature 80°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.504 Hx0.382W x 0.276 D 12.80mmx9.70mmx7.00mm
Published 2007
Packaging Bulk
Physical
Number of Pins 10
Package / Case 10-DIP (0.300, 7.62mm)
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
