HDSP-0881
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.600, 15.20mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Alphanumeric Displays Module 1DIGIT 20LED Yellow 8-Pin DIP
PDF
/
Buying Options
Total Price: USD $292.6
Unit Price: USD $292.596833
≥1 USD $292.596833
≥200 USD $116.74832
≥500 USD $112.846381
≥1000 USD $110.919044
Inventory: 4406
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Character Height 7.4mm
Viewing Area (height) 7.4mm
Height 13.4874mm
Technical
Dominant Wavelength 585 nm
Common Pin Common Anode
Digit/Alpha Size 0.29 7.37mm
Number of Characters 1
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 583nm
Millicandela Rating 0.22mcd ~ 2.39mcd
Luminous Intensity 2.39 mcd
Forward Voltage 1.9V
Forward Current 10mA
Optoelectronic Device Type SMART/NORMAL 4 X 7 DOT MATRIX LED DISPLAY
Power Dissipation 963mW
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Configuration COMPLEX
Number of Elements 20
Depth 13.5mm
Number of Functions 1
Voltage - Rated DC 5V
Subcategory LED Displays
Additional Feature BUILT IN MEMORY, WITH DECODER/DRIVER, TTL COMPATIBLE, HIGH RELIABILITY
Color Yellow
Min Operating Temperature -55°C
Max Operating Temperature 100°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.531 Hx0.402W x 0.169 D 13.50mmx10.20mmx4.30mm
Series HDSP-088x
Published 2008
Packaging Bulk
Physical
Number of Pins 8
Package / Case 8-DIP (0.600, 15.20mm)
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
