HDSP-0771
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.600, 15.20mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
Numeric Displays Module 1DIGIT 20LED Hi-Eff. Red 8-Pin DIP
PDF
/
Buying Options
Total Price: USD $98.38
Unit Price: USD $98.37691
≥1 USD $98.37691
≥200 USD $39.253084
≥500 USD $37.941497
≥1000 USD $37.292925
Inventory: 4771
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Through Hole
Package / Case 8-DIP (0.600, 15.20mm)
Number of Pins 8
Technical
Packaging Bulk
Published 2008
Series HDSP-077x
Size / Dimension 0.531 Hx0.402W x 0.169 D 13.50mmx10.20mmx4.30mm
JESD-609 Code e1
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Max Operating Temperature 85°C
Min Operating Temperature -55°C
Color Red
Additional Feature BUILT-IN MEMORY, WITH DECODER/DRIVER, TTL COMPATIBLE
Subcategory LED Displays
Voltage - Rated DC 5V
Number of Functions 1
Depth 13.5mm
Operating Supply Voltage 5V
Number of Elements 20
Configuration COMPLEX
Max Supply Voltage 5.5V
Min Supply Voltage 4.5V
Power Dissipation 963mW
Optoelectronic Device Type SMART/NORMAL 4 X 7 DOT MATRIX LED DISPLAY
Forward Current 120mA
Current - Test 10mA
Forward Voltage 1.75V
Luminous Intensity 1.82 mcd
Millicandela Rating 0.26mcd ~ 1.82mcd
Wavelength - Peak 635nm
Display Type 7-Segment
Reverse Voltage 5V
Number of Characters 1
Digit/Alpha Size 0.29 7.37mm
Common Pin Common Anode
Dominant Wavelength 626 nm
Dimensions
Height 13.4874mm
Viewing Area (height) 7.4mm
Character Height 7.4mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
