HDSP-0760
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.600, 15.20mm)
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED DISPLAY 4X7 7.4MM HE RED
PDF
/
Buying Options
Total Price: USD $70.89
Unit Price: USD $70.8928
≥1 USD $70.8928
≥10 USD $60.888256
≥100 USD $57.843808
Inventory: 154
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Character Height 7.4mm
Viewing Area (height) 7.4mm
Height 13.4874mm
Technical
Dominant Wavelength 626 nm
Common Pin Common Anode
Digit/Alpha Size 0.29 7.37mm
Number of Characters 1
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 635nm
Millicandela Rating 0.06mcd ~ 1.17mcd
Luminous Intensity 140 μcd
Forward Voltage 1.6V
Current - Test 10mA
Optoelectronic Device Type SMART/NORMAL 4 X 7 DOT MATRIX LED DISPLAY
Power Dissipation 573mW
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Configuration COMPLEX
Number of Elements 20
Depth 13.5mm
Number of Functions 1
Voltage - Rated DC 5V
Subcategory LED Displays
Additional Feature BUILT-IN MEMORY, WITH DECODER/DRIVER, TTL COMPATIBLE
Color Red
Min Operating Temperature -55°C
Max Operating Temperature 85°C
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e1
Size / Dimension 0.531 Hx0.402W x 0.169 D 13.50mmx10.20mmx4.30mm
Series HDSP-076x
Published 2011
Packaging Tray
Physical
Number of Pins 8
Package / Case 8-DIP (0.600, 15.20mm)
Mount Through Hole
Supply Chain
Factory Lead Time 16 Weeks
