HDSM-541C

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 10-SMD, No Lead
Category Optoelectronics / Display Modules - LED Character and Numeric
Description BROADCOM LIMITED HDSM-541C 7-Segment LED Display, Red, 20 mA, 2 V, 16 mcd, 2, 14.22 mm
PDF
/
Buying Options
Total Price: USD $5.4
Unit Price: USD $5.4032
≥1 USD $5.4032
≥10 USD $3.82184
≥100 USD $3.130072
Inventory: 134
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC

Dimensions

Character Height 14.22mm
Viewing Area (height) 14.22mm
Height 16.9926mm

Technical

Dominant Wavelength 624 nm
Common Pin Common Anode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 2
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 632nm
Millicandela Rating 16mcd
Luminous Intensity 16 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Power Dissipation 65mW
Element Configuration Common Anode
Power Dissipation-Max 65mW
Number of Elements 16
Operating Supply Voltage 2V
Depth 19mm
Number of Functions 2
Subcategory LED Displays
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.669 Hx0.984W x 0.148 D 17.00mmx25.00mmx3.75mm
Published 2008
Packaging Tape & Reel (TR)

Physical

Number of Pins 10
Package / Case 10-SMD, No Lead
Mount Surface Mount

Supply Chain

Factory Lead Time 16 Weeks
