HDSM-533C
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD, No Lead
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED DISPLAY, SMD, 14.2MM, RED, CC
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 14.22mm
Viewing Area (height) 14.22mm
Height 16.9926mm
Technical
Dominant Wavelength 624 nm
Common Pin Common Cathode
Digit/Alpha Size 0.56 14.22mm
Number of Characters 1
Forward Voltage-Max 2.6V
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 632nm
Millicandela Rating 16mcd
Luminous Intensity 16 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Power Dissipation 65mW
Element Configuration Common Cathode
Power Dissipation-Max 65mW
Number of Elements 8
Operating Supply Voltage 2V
Depth 19mm
Number of Functions 1
Subcategory LED Displays
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.669 Hx0.492W x 0.148 D 17.00mmx12.50mmx3.75mm
Published 2010
Packaging Tape & Reel (TR)
Physical
Number of Pins 10
Package / Case 10-SMD, No Lead
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
