HDSM-443F
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD, No Lead
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED DISPLAY, SMD, DUAL, 10MM, YLW, CC
PDF
/
Buying Options
Total Price: USD $5.61
Unit Price: USD $5.61396
≥1 USD $5.61396
≥200 USD $2.24112
≥500 USD $2.166285
≥1000 USD $2.128211
Inventory: 9695
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Package / Case 10-SMD, No Lead
Number of Pins 10
Technical
Packaging Tape & Reel (TR)
Published 2016
Size / Dimension 0.512 Hx0.772W x 0.148 D 13.00mmx19.60mmx3.75mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Yellow
Subcategory LED Displays
Number of Functions 2
Depth 15mm
Operating Supply Voltage 2.1V
Number of Elements 16
Power Dissipation-Max 65mW
Element Configuration Common Cathode
Power Dissipation 65mW
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Forward Current 25mA
Current - Test 20mA
Luminous Intensity 15 mcd
Wavelength - Peak 591nm
Display Type 7-Segment
Reverse Voltage 5V
Number of Characters 2
Digit/Alpha Size 0.39 10.00mm
Common Pin Common Cathode
Dominant Wavelength 589 nm
Dimensions
Height 13.0048mm
Viewing Area (height) 10mm
Character Height 10mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
