HDSM-443C

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 10-SMD, No Lead
Category Optoelectronics / Display Modules - LED Character and Numeric
Description BROADCOM LIMITED HDSM-443C 7-Segment LED Display, Red, 20 mA, 2 V, 14.3 mcd, 2, 10 mm
PDF
/
Buying Options
Total Price: USD $5.02
Unit Price: USD $5.016
≥1 USD $5.016
≥10 USD $3.54904
≥100 USD $2.906552
Inventory: 1127
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Surface Mount
Package / Case 10-SMD, No Lead
Number of Pins 10

Technical

Packaging Tape & Reel (TR)
Published 2008
Size / Dimension 0.512 Hx0.772W x 0.148 D 13.00mmx19.60mmx3.75mm
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Red
Subcategory LED Displays
Number of Functions 2
Depth 15mm
Operating Supply Voltage 2V
Number of Elements 16
Power Dissipation-Max 65mW
Element Configuration Common Cathode
Power Dissipation 65mW
Forward Current 20mA
Luminous Intensity 14.3 mcd
Millicandela Rating 14.3mcd
Wavelength - Peak 644nm
Display Type 7-Segment
Reverse Voltage 5V
Forward Voltage-Max 2V
Number of Characters 2
Digit/Alpha Size 0.39 10.00mm
Common Pin Common Cathode
Dominant Wavelength 630 nm

Dimensions

Height 13.0048mm
Viewing Area (height) 10mm
Character Height 10mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
