HDSM-293C
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD, No Lead
Category Optoelectronics / Display Modules - LED Character and Numeric
Description
LED DISPLAY, SMD, DUAL, 7MM, RED, CC
PDF
/
Buying Options
Total Price: USD $3.53
Unit Price: USD $3.5288
≥1 USD $3.5288
≥10 USD $2.4948
≥100 USD $2.091408
Inventory: 1453
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Character Height 7mm
Viewing Area (height) 7mm
Height 10.0076mm
Technical
Dominant Wavelength 624 nm
Common Pin Common Cathode
Digit/Alpha Size 0.28 7.00mm
Number of Characters 2
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 632nm
Peak Reverse Current 100μA
Millicandela Rating 7.5mcd
Luminous Intensity 7.5 mcd
Forward Current 20mA
Optoelectronic Device Type SMART/NORMAL 7 SEG NUMERIC LED DISPLAY
Power Dissipation 65mW
Element Configuration Common Cathode
Number of Elements 18
Operating Supply Voltage 2V
Depth 12mm
Number of Functions 2
Subcategory LED Displays
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 105°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.394 Hx0.594W x 0.148 D 10.00mmx15.10mmx3.75mm
Published 2010
Packaging Tape & Reel (TR)
Physical
Number of Pins 10
Package / Case 10-SMD, No Lead
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 16 Weeks
