HDSM-291C

Broadcom Limited
RoHS
RoHS RoHS compliant
Package 10-SMD, No Lead
Category Optoelectronics / Display Modules - LED Character and Numeric
Description AVAGO TECHNOLOGIES HDSM-291C 7-Segment LED Display, Surface Mount, 2, 7 mm, Red, Common Anode, 7.5 mcd, 20 mA
PDF
/
Buying Options
Total Price: USD $5.02
Unit Price: USD $5.016
≥1 USD $5.016
≥10 USD $3.54904
≥100 USD $2.906552
≥500 USD $2.450254
Inventory: 1193
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Character Height 7mm
Viewing Area (height) 7mm
Height 10.0076mm

Technical

Dominant Wavelength 624 nm
Common Pin Common Anode
Digit/Alpha Size 0.28 7.00mm
Number of Characters 2
Reverse Voltage 5V
Display Type 7-Segment
Wavelength - Peak 632nm
Millicandela Rating 7.5mcd
Luminous Intensity 7.5 mcd
Forward Current 20mA
Power Dissipation 65mW
Element Configuration Common Anode
Power Dissipation-Max 65mW
Number of Elements 18
Operating Supply Voltage 2V
Depth 12mm
Number of Functions 2
Subcategory LED Displays
Color Red
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.394 Hx0.594W x 0.148 D 10.00mmx15.10mmx3.75mm
Published 2008
Packaging Tape & Reel (TR)

Physical

Number of Pins 11
Package / Case 10-SMD, No Lead
Mount Surface Mount

Supply Chain

Factory Lead Time 16 Weeks
